This article compares OFC (Optical Fiber Cable) and FSO (Free Space Optics), highlighting the distinctions between these two optical communication technologies.

Introduction:

Both OFC and FSO operate within the optical domain. OFC relies on physical cables to transmit modulated light, while FSO uses the air as its transmission medium. The choice between them depends on factors like range, data rate requirements, security concerns, and the specific environment. Let’s delve into the key differences.

OFC (Optical Fiber Cable)

An OFC consists of numerous optical fibers bundled together and protected by plastic sheathing. These cables facilitate high-speed data transfer over long distances (hundreds of miles) by transmitting data signals as light.

All OFCs utilize a core of transparent silicon, similar in size to a human hair, surrounded by a cladding layer with a lower refractive index. This design prevents light leakage. Fiber optic cables have found applications across diverse industries, including medicine, data storage, telecommunications, networking, broadcasting/CATV, and broadband internet.

fiber optic communication tutorial

The diagram above illustrates a typical optical communication system, comprising a transmitter, the OFC, and a receiver. The transmitter includes an encoder and a light source (LED/Laser Diode), while the receiver incorporates a photodetector and a decoder.

fiber optic cable

Advantages of OFCs:

  • High Bandwidth: Offers significantly greater bandwidth than traditional metal cables.
  • Low Power Loss: Experiences less power loss compared to copper cables, enabling longer transmission distances (around 2 km versus copper’s ~100 meters).
  • Immunity to EMI: Resistant to electromagnetic interference; electrical noise does not affect the signal.
  • High Capacity & Small Size: Supports 4.5 times the capacity of wire cables with a 30 times smaller cross-sectional area.
  • Thin & Lightweight: OFCs are much thinner and lighter than copper cables.
  • Security: Difficult to tap into undetected, making them a more secure option for transmitting sensitive data compared to FSO. Requires specialized skills to intercept.
  • Strength & Durability: Possesses greater tensile strength, is flexible, and resists most corrosive elements.

FSO (Free Space Optics)

FSO is a wireless optical communication technology that transmits data through free space (air, vacuum, or outer space). Similar to OFC, FSO finds use in telecommunications and computer networking.

Common FSO applications include metropolitan area networks (MANs), last-mile access, backhaul solutions, enterprise connectivity, fiber backup systems, and service acceleration.

FSO systems transmit data between two buildings within a direct Line of Sight (LOS) using light waves.

The diagram below shows a simplified FSO system consisting of a transmitter, the atmospheric channel (air), and a receiver. Like OFC, the FSO transmitter has a data encoder and a light source (LED/Laser Diode) with its driver. The FSO receiver includes a photodetector, signal processing module, and data decoder. FSO commonly uses wavelengths of 800 nm and 1550 nm.

FSO Block Diagram

Advantages of FSO:

  • License-Free: No licensing is required for transmitting laser beams through the air.
  • Easy Installation: Installation is typically easier and faster. Maintenance time is also generally shorter.
  • Moderate Cost: The overall cost is moderate compared to OFC deployment.
  • High Power Operation: Can operate at higher power levels.
  • High Bit Rates & Low BER: Offers higher bit rates and lower bit error rates (BERs).
  • Immunity to EMI: Resistant to electromagnetic interference.

Difference between OFC and FSO

The following table compares OFC and FSO to highlight their key differences:

SpecificationsOFCFSO
Full formOptical Fiber CableFree Space Optics
Transmitting mediumCable (Single mode and multimode)Space or Air
LicensingRequired for laying cablesNot required, as it uses air as the medium
Installation & MaintenanceDifficultEasy
CostExpensiveCheaper than OFC
MobilityNot feasible once laid outPossible due to system components and medium
SecurityDifficult to intercept, more secureEasier to intercept, less secure
Data rate100 Mbps - 10 Gbps (distance dependent)Maximum 10 Gbps (Line of Sight)
Transmission distanceUp to 2 Km (multimode)About 1.5 Km (at 155 Mbps data rate)
ApplicationsPoint to Point (long distance)Between buildings, last mile solution (short distance)
