RFPasternack Launches 60GHz Tx/Rx Waveguide Modules and Development System
Advertisement
Pasternack has recently launched a new 60GHz Tx/Rx waveguide system, including transmitter and receiver modules, designed to operate within the 60GHz frequency range.
On October 1, 2013, Pasternack announced the release of their innovative 60 GHz Waveguide Modules and Development System. This system aims to provide R&D labs, engineers, and developers with a quick and easy way to experiment with 60 GHz technology.
Potential applications include:
- Point-to-point links (cellular backhaul)
- GigE wireless LAN (WiGig)
- Radiometry
- Uncompressed HD video
- FMCW 60 GHz radar
- Scintillometry
- Campus networks
- Multi-gigabit remote sensing based wireless communications
The system operates within the unlicensed frequency spectrum of 57GHz to 64GHz, a millimeter wave ISM band available globally.
Developed in partnership with Vubiq, this 60 GHz RF system simplifies the design of high-bandwidth products. It features a user-friendly GUI for configuration via a USB interface and utilizes a standard WR-15 V-band waveguide interface.
The system supports modulation bandwidths up to 1.8 GHz and is well-suited for developing systems based on 802.11ad, 802.11aj, or any 540MHz/500MHz channel system.
About the 60GHz Development System
The 60GHz development system includes the following:
- Easy-to-use interface software
- Waveguide SiGe Transmitter Module
- Waveguide SiGe Receiver Module
- WR15 Rx Board
- WR15 Tx Board
- Mounting Brackets
- (2) Tripods
- (2) AC-DC Power Adapters
- (2) USB interface Cables
- Expansion kit with phase-matched baseband coaxial cables
Additional accessories, such as antennas (horn), IQ modules, and cables, may be available for separate purchase.
Product IDs
- Complete Development system: PEM003-KIT
- 60GHz waveguide transmitter module: PEM001
- 60Ghz waveguide receiver module: PEM002
Applications
- 802.11ad
- 802.11aj
- Point-to-point / Backhaul Radio Links
- HD video
- RADAR
- Radiometry
- Ethernet
- Remote Sensing
About Pasternack Enterprises, Inc.
Pasternack Enterprises, Inc. is a global supplier of RF and Microwave components, supported by an expanding network of 17 international distributors, serving customers in over 32 countries worldwide. Pasternack has been serving the RF/Microwave community for over 40 years.
